DG-GR6821AC
DIGISOL XPON ONU 1200MBPS WIRELESS ROUTER WITH 1 PON, 2 GE PORTS & 1 FXS PORT
Product Key Features
- Dual Mode ONU technology (GPON/GEPON)
- Features auto-detecting, auto-configuration and auto firmware upgrade etc.
- Integrated OAM/OMCI remote configuration and maintenance function
- Support Wi-Fi 5 (802.11ac)
- Support IPv4 and IPv6 dual stack
- Integrated line testing compliant with GR-909 on POTS
- Support NAT, Firewall function
- Support DHCP/ Static/ PPPoE mode WAN connections
- Support IGMP Snooping
- Plug and Play
- 3 Years Warranty
XPON ONU
Product Specifications
- Support Bridge, Route and Bridge/ Route mixed mode
- Support IGMP v1/v2/v3 snooping /proxy
- Support MLD v1/v2 snooping / proxy
- Support 4 queues
- Support SP and WRR
- Support 802.1P
- Support DSCP
- Support IPv4, IPv6 and IPv4/IPv6 dual stack
- Support DHCP/PPPOE/Static
- Support Static route
- Support DHCP Server
- Support NAT
- Support DMZ
- Support Virtual Server
- Support DDNS
- Support Firewall
- Support MAC filter based on MAC or URL
- Support ACL
- Call protocol: SIP(IMS compatible) seamless compatible with all popular call agent
- Integrate heartbeat function and support active/standby call agent
- Voice coding: ITU-T G.711/G.722/G.729, auto-negotiate with call agent
- Echo cancellation exceeding ITU-T G.165/G.168-2002, up to 128ms tail
length - Support high/low speed fax, bypass fax and T38 fax
- Support high speed MODEM(56Kbps) dial access
- Support RFC2833 and redundant RFC2833, difference rings, Md5 authentication, call forward, call waiting, hot-line call, alarm clock, and all kinds of value-added voice service
- Multi-party conferencing
- Support Wireless AP mode
- Support 802.11 b/g/n/ac
- Support Multiple SSID
- Support Wireless encryption
- OAM/ OMCI
- Telnet
- WEB
- TR069
- Support full management of HGU functions by DIGISOL OLT
- 178mm x 120mm x 30mm (LxWxH)
0.32kg
